Differential Pressure Transmitter Manufacturer
Aranka Instruments LLP is a trusted Differential Pressure Transmitter Manufacturer and Supplier in Ahmedabad, offering precision-engineered transmitters designed to measure liquid levels, density, and pressure differences in industrial systems. These instruments are ideal for monitoring tanks, pipelines, and process vessels across industries such as chemical, pharmaceutical, power generation, water treatment, and oil & gas. The transmitter operates on the differential pressure measurement principle, where the pressure difference between two points of a liquid column is used to determine the level or flow of the medium accurately.
Built using advanced sensing technology and robust construction, the Aranka Differential Pressure Transmitter ensures exceptional accuracy, long-term stability, and reliable performance in both static and dynamic process conditions. It converts pressure variations into standardized electrical signals (4–20 mA or digital output), making it easy to integrate with PLC, SCADA, or DCS systems. Compact, corrosion-resistant, and easy to calibrate, this transmitter provides a dependable solution for level, pressure, and flow measurement in challenging industrial environments.
- Full bore type
- Simple construction
- Provides wide flow ranges
- Outstanding accuracy
- Operates over wide ranges of temperature & pressure
- Easy maintenance as no moving parts
- Pulsed DC coil excitation
- Integral grounding
| Power Supply | 100 ~260 VAC @ 50Hz OR 24VDC | |
| Line Size | 20 NB to 300 NB | |
| Sensor Electrode | S.S. 316 / Hastelloy C / Titanium / Tantalum | |
| Lining | PTFE / FEP / Hard Rubber [80 nm to 300 NM] | |
| Process Media | Liquid | |
| Transmitter Mounting | Local / Remote | |
| Analogue output | 4-20mA | |
| Communication Output | RS 485 Modbus RTU | |
| Process Connections | DIN, ANSI Flanges, Tri-Clamp | |
| Max. Pressure | 15 Bar | |
| Max. Temperature | -20 ~120’C | |
| Additional Features | Fluid Empty Indicator, Velocity | |
CE Approved
ISO 9001 : 2025
Frequently Asked Questions (FAQs)
What is a Differential Pressure Transmitter?
A differential pressure transmitter measures the difference in pressure between two points and converts it into an electrical signal. It is commonly used to measure liquid level, flow rate, or pressure drop in industrial systems.
How does the Differential Pressure Transmitter work?
It measures the pressure difference between the high-pressure and low-pressure sides of a tank or pipe. The resulting pressure differential corresponds to the liquid height or flow velocity and is converted into an electronic output signal.
What is the operating principle of this transmitter?
The device works on Faraday’s Law of Electromagnetic Induction, where a voltage is induced in a conductive fluid moving through a magnetic field. This voltage, proportional to the flow velocity, is amplified and processed to calculate the flow or level value.
What are the key features of Aranka’s Differential Pressure Transmitter?
-
High measurement accuracy and repeatability
-
Stable 4–20 mA or digital Modbus output
-
Temperature-compensated signal processing
-
Compact, rugged, and corrosion-resistant body
-
Suitable for clean and viscous liquids
In which industries can it be used?
It is ideal for chemical, pharmaceutical, water & wastewater, oil & gas, power, and food & beverage industries — wherever accurate differential pressure or level monitoring is required.
What are the typical output options available?
Standard output is 4–20 mA, with optional RS-485 (Modbus RTU) communication for digital control and remote monitoring.
How is the transmitter installed and maintained?
The device is installed by connecting the high- and low-pressure ports to appropriate process points. Routine calibration and keeping the ports free from blockages ensure long-term reliable operation.
Why choose Aranka Instruments LLP?
As a leading Differential Pressure Transmitter Manufacturer in Ahmedabad, Aranka Instruments provides high-performance products with superior accuracy, durable design, and complete support for industrial automation and fluid monitoring applications.
