ALC-96 Universal Level Controller – Leading Manufacturer & Supplier in Ahmedabad

Aranka Instruments LLP, a trusted Level Controller Manufacturer and Supplier in Ahmedabad, Gujarat, India, offers the advanced ALC-96 Universal Level Controller, engineered for precision and reliability in industrial level monitoring and control systems.

This high-performance controller is designed to meet the demanding needs of water treatment plants, chemical processing units, and manufacturing industries, ensuring accurate level measurement and efficient process automation.

As a Level Controller Manufacturer and Supplier in Ahmedabad, Aranka Instruments is known for delivering innovative, durable, and user-friendly industrial instrumentation. Every ALC-96 unit is designed with precision engineering to provide long-term reliability and hassle-free performance.

Key Features of ALC-96 Universal Level Controller

  • Dual Measurement Modes:
    The ALC-96 supports both Height Level Measurement (mm, cm, inch, ft, m) and Volumetric Measurement (mL, L, kL), allowing users to choose the most suitable unit for their application.

  • 4 Independent Set Points:
    Equipped with four potential-free relay outputs, the controller allows multiple level-based operations or alarms, ensuring complete control flexibility.

  • Front-Key Calibration:
    Simplifies configuration with front-panel calibration, eliminating the need to open the enclosure—enhancing user safety and minimizing downtime.

  • Universal Application:
    Suitable for tanks, vessels, sumps, and various industrial systems requiring accurate and stable level control.

Features

ALC 96 is Universal Level Controller
ALC 96 can programma in two Types of measurement
a) Height level measurement like mm,cm,inch,Ft.,Mtr.
b) Volumetric Measurement like ml, Ltr., Kltr.
ALC 96 have 4 different set points with 4 different Potential Free Relay Output
ALC 96 Can use for any level controlling application
ALC 96 Can Calibrat From Front Key

Specifications

Power Supply 100 ~260 VAC @ 50Hz
Input 4-20mA
Relay Output 3A 1 CO 2nos
Analogue Output 4-20mA
Display LCD
Range mm, Volume
Calibration Front Key
Mounting Panel Mount
Size 96x96x85mm
Cut out 92×92 mm
Enclosure MOC ABS
Operating Temperature Max. 55’C

Application Notes

  • Any Tank Level Controlling
  • Tank Level Measurement in mm
  • Tank Volume Controlling.

Frequently Asked Questions (FAQs)

What measurement modes does ALC-96 support?

The ALC-96 supports two measurement modes:

  • Height mode (units like mm, cm, inch, ft, m)

  • Volumetric mode (units like mL, L, kL)

How many setpoints and relay outputs are available?

There are 4 independent setpoints, each driving a potential-free relay output, enabling flexible control logic in one device.

How is calibration done?

Calibration is performed via front keys (zero/span, unit selection) on the panel — no need to open the enclosure.

What are the input and output signals?

  • Input: 4-20 mA

  • Outputs: Relay outputs (3 A, 1 common + 2 NO/NC) and analog 4-20 mA output

What are the power and mounting specifications?

  • Power supply: 100–260 VAC @ 50 Hz

  • Mounting: Panel mount (cut-out 92 × 92 mm)

  • Unit dimensions: 96 × 96 × 85 mm

  • Enclosure material: ABS

What is the operating temperature range?

The device’s typical operating temperature is up to 55 °C

For what applications is ALC-96 suitable?

It is ideal for various level control tasks such as:

  • Tank level monitoring & control

  • Volume batching / volumetric control

  • High/low level alarms

  • Sump control, overflow protection, process vessels

Does the unit come with documentation and approvals?

Yes — the product page offers a catalog, manual, drawings, plus CE approval and ISO 9001 certification.
